From PostAuth RCE to PreAuth RCE on Liferay Portal

The post presents a discovery about CVE-2019-16891 that allows exploiting this vulnerability on Liferay Portal without authentication as everyone knows.

About CVE-2019-16891

References

• The public announcement of Liferay

Liferay Portal 7.1.0 and earlier is vulnerable to remote code execution (RCE) via deserialization of JSON data.

• NVD database

According to NVD database, CVE-2019-16891 has a CVSS score of 8.8

because it requires an account on Liferay to exploit successfully.

Privileges Required (PR): Low

• Analysis from VNPT Cyber Immunity

The root cause

Liferay overridden deserialize func when implementing JSONFactoryImpl class from com.liferay.portal.kernel.json.JSONFactory

@Override
	public Object deserialize(String json) {
		try {
			return _jsonSerializer.fromJSON(json);
		}

We can see the actual deserialization issue is deeper:

1. deserialize() call fromJSON()

2. fromJSON() call unmarshall() : https://github.com/Servoy/jabsorb/blob/master/src/org/jabsorb/JSONSerializer.java#L262

3. So the vulnerability is inside org.jabsorb.JSONSerializer library.

Liferay Team was fixed in 2018 by implementing getClassFromHint to whitelist during deserialization.

• https://github.com/liferay/liferay-portal/blame/master/portal-impl/src/com/liferay/portal/json/jabsorb/serializer/LiferayJSONSerializer.java#L68-L82

Found Second Vulnerable Endpoint

After determining the root cause. I searched the source code for locations using the deserialize function with the keyword JSONFactoryUtil.deserialize. A sufficient condition for successful exploiting is that the parameter passed to JSONFactoryUtil.deserialize is taint from user input.

And this is the location I found: https://github.com/liferay/liferay-portal/blob/6.2.x/portal-impl/src/com/liferay/portal/action/PortletURLAction.java#L167:L172

The endpoint is map to Portlet URL feature (turn off by default) and here is the endpoint that can be successfully called without authentication:

PoC

POST /c/portal/portlet_url HTTP/1.1
Host: liferay.victim.example.com
User-Agent: Mozilla/5.0
Accept: */*
Accept-Language: en-US,en;q=0.5
Accept-Encoding: gzip, deflate
X-Requested-With: XMLHttpRequest
Content-Type: application/x-www-form-urlencoded; charset=UTF-8
Origin: http://liferay.victim.example.com
Connection: close
Referer: http://liferay.victim.example.com

parameterMap={"Json payload for deserialization in here!"}

Detect vulnerable Liferay Portal instance

• GET /c/portal/portlet_url return 200 status code

• Version <= 7.1.0

Conclusion

• New CVSS score: 9.8 - Critical (https://nvd.nist.gov/vuln-metrics/cvss/v3-calculator?vector=AV:N/AC:L/PR:N/UI:N/S:U/C:H/I:H/A:H&version=3.1)

• Upgrade Liferay Portal (https://liferay.dev/portal/security/known-vulnerabilities/-/asset_publisher/jekt/content/cst-7111)

  • Liferay Portal 7.1: There is no patch available for Liferay Portal 7.1.0. Instead, users should upgrade to Liferay Portal 7.1 CE GA2 (7.1.1) or later.

  • Liferay Portal 7.0: Source patch for Liferay Portal 7.0 GA7 (7.0.6) is available on GitHub. Details for working with source patches can be found on the Patching Liferay Portal page.

  • Liferay Portal 6.2: Source patch for Liferay Portal 6.2 GA6 (6.2.5) is available on GitHub. Details for working with source patches can be found on the Patching Liferay Portal page.



Update

• 12/21/2022: NVD rescored CVSS to 9.8 for this vulnerability

• 12/27/2022: MITRE added my advisory to the References
